PP-600D-F Laboratory 25T Hydraulic Heat Press max 800 degree with 180mm plate size

PP-600D-F Serial Press is a 25 ton programmable control Heatable press with double heating plate.It has 300 degree, 500 degree and 800 degree heating temperature for option. Plate size 180*180mm

Inquire Now Next Product

Products Description

Model No.	PP-600D-F
Pressing range	0.01~25T
Pressing accuracy	0.01T
Max heating temperature	RT~300℃ ;2.2kw	RT~500℃ ;3.4kw	RT~800℃ ;6kw
Controller	7-inch (IPS HD) touch screen
Pressing mothed	18 steps Program Pressing-Holding-Auto Pressure Relief-Auto Sample Removal
Pressure Conversion	Adjustable pressure increase speed
Curve Graph	Displays operation curve for each run; supports U disk download as Excel file
Cooling method	Water cooling
Heating plate size	180*180mm
Working space	210*65mm
Dimension	480480750mm
Power supply	AC220V/50Hz; 110V can customize
