The CHY-FP2000 High-Energy Planetary Ball Mill is designed with 490×430×420 mm size can put in glove box for space-constrained and controlled-atmosphere environments.It can equip with 4pcs 500ml grinding jar for laboratory large particle samples processing .It is also equipped with a durable digital panel for precise control of time, speed, and grinding modes (continuous, intermittent, and bidirectional rotation.
| Model No. | CHY-FP2000 |
| Feed Sample Size | <10mm |
| Capacity of Grinding Jar | 500ml*4pcs; |
| Max processing capacity | 2000ml |
| Max Feeding Capacity | 2/3 capacity of the grinding jar |
| Output sample size range | 0.1-20 um |
| Max speed | 800 r/min |
| Mode of motion | X-axis planetary motion |
| Grinding jar material | Tungsten carbide | Zirconia | Agate | Stainless steel | MC nylon optional |
| Grinding method | Dry grinding and wet grinding |
| Machine function | Continuous and alternating forward and reverse operation, timed speed regulation, power-off memory | Emergency stop, overload and dangerous operation protection, temperature monitoring | High temperature protection |
| Power Supply | 100-120V/200-240V AC ,50-60Hz,750W |
| Dimension | 430*490*420mm |
